Safety
Automatic Stuf-Off | No |
Overheat Safety System | No |
Residual Heat Indicators | NA |
Child lock | No |
Anti-over flow | No |
Hob Features
Hob Type | Gas |
Type of Pan Support | - |
Ignition | Integrated Ignition |
Fuel | Gas |
Cast Iron Pan Supports | Yes |
Burners/Heating zones
No. Of Burners/Heating zones | 4 Gas + 1 Wok |
Front left (kW) | 1 |
Rear left (kW) | 2.9 |
Front right (kW) | 1.75 |
Rear right (kW) | 1.75 |
Central (kW) | 5 kW |
Number of Cooking Levels | NA |
Hob Controls
Timer | NA |
Control Type | Knob Control |
Type | Gas |
Dimensions & Weights
Product Height (mm) | 46 |
Product width (mm) | 750 |
Product depth (mm) | 510 |
Carton height (mm) | 180 |
Carton width (mm) | 830 |
Carton depth (mm) | 610 |
Net Weight (kg) | 13.40 kg |
Gross Weight (kg) | 14.80 kg |
Installation
Worktop Cut Out (HxWxD) (mm) | hX560X490 |
Easy Installation | No |
Consumption Values & Other Technical Specification
CE Approved / Requested Standards | CE; UKCA |
Model Codes
CIHYG32SXE | EAN:8690842534430 |
