Safety
Automatic Stuf-Off | No |
Residual Heat Indicators | No |
Child lock | No |
Anti-over flow | No |
Hob Features
Type of Pan Support | - |
Ignition | - |
Hob on indicator+Residual heat indicator | Yes |
Fuel | Electric |
Type | Ceramic Glass |
General Features
Type | Built-in Electric Hob |
Burners/Heating zones
No. Of Burners/Heating zones | 4 Vitroceramic |
Front left (kW) | 1.7 |
Rear left (kW) | 1.2 |
Front right (kW) | 1.2 |
Rear right (kW) | 1.7 |
Central (kW) | NA |
Number of Cooking Levels | 6 |
Hob Controls
Control Type | Knob Control |
Timer | No |
Location | Front control |
Type | Electric |
Knob Type | BYK1 |
Dimensions & Weights
Product Height (mm) | 37 |
Product width (mm) | 580 |
Product depth (mm) | 510 |
Carton height (mm) | 125 |
Carton width (mm) | 655 |
Carton depth (mm) | 550 |
Net Weight (kg) | 8.300 kilograms |
Gross Weight (kg) | 8.600 kilograms |
Installation
Worktop Cut Out (HxWxD) (mm) | hX560X490 |
Easy Installation | No |
Worktop cut out W (mm) | 560 |
Worktop cut out D (mm) | 490 |
Total power load (kW) | 5.8 |
Consumption Values & Other Technical Specification
CE Approved / Requested Standards | CE; EMC; LVD |
CE Approved | Yes |
Model Codes
HIC64102 | EAN:5023790022422 |
